    • hyperledger fabric 백업 및 복구
      How to Dev 2020. 12. 29. 14:33

      hyperleder backup and restore

      fabric data backup

      1. crypto material (crypto-config)
      2. Channel artifacts (channel-artifacts folder)
      3. Peers, Orderer( /var/hyperledger/production directory/docker volumes)

      기본 환경은 fabric-samples의 test-network를 기준으로 함

      1~3단계는 ./network.sh up 명령어를 사용

      1. 암호화 자료 생성

        cd fabric-samples/test-network
export PATH=${PWD}/../bin:${PWD}:$PATH
# Crypto material in network components
cryptogen generate --config=./organizations/cryptogen/crypto-config-orderer.yaml --output="organizations"
cryptogen generate --config=./organizations/cryptogen/crypto-config-org1.yaml --output="organizations"
cryptogen generate --config=./organizations/cryptogen/crypto-config-org2.yaml --output="organizations"

      2. Consortium Genesis Block 생성

        # system-genesis-block
export FABRIC_CFG_PATH=${PWD}/configtx
# export FABRIC_CFG_PATH=$PWD/../config/
configtxgen -profile TwoOrgsOrdererGenesis -channelID system-channel -outputBlock ./system-genesis-block/genesis.block

      3. Test Network 시작

        IMAGE_TAG=latest docker-compose -f docker/docker-compose-test-net.yaml up -d

      4. Join Peers of Both Organizations to mychannel

        # 채널 생성 step5의 체인코드 항목으로 이동 , 이동전 채널 genesis 블럭 생성의 환경 변수 설정
./network.sh createChannel
# 채널 아티팩트 생성
mkdir -p channel-artifacts
configtxgen -profile TwoOrgsChannel -outputCreateChannelTx ./channel-artifacts/mychannel.tx -channelID mychannel
configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/Org1MSPanchors.tx -channelID mychannel -asOrg Org1MSP
configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/Org2MSPanchors.tx -channelID mychannel -asOrg Org2MSP
# 채널 genesis 블럭 생성
export ORDERER_CA=${PWD}/organizations/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem
export PEER0_ORG1_CA=${PWD}/organizations/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
export PEER0_ORG2_CA=${PWD}/organizations/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
export FABRIC_CFG_PATH=$PWD/../config/
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer channel create -o localhost:7050 -c mychannel --ordererTLSHostnameOverride orderer.example.com -f ./channel-artifacts/mychannel.tx --outputBlock ./channel-artifacts/mychannel.block --tls true --cafile $ORDERER_CA
# 채널 조인(org1)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer channel join -b ./channel-artifacts/mychannel.block
# 채널 조인(org2)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer channel join -b ./channel-artifacts/mychannel.block
# 업데이트 앵커 피어(org1)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer channel update -o localhost:7050 --ordererTLSHostnameOverride orderer.example.com -c mychannel -f ./channel-artifacts/Org1MSPanchors.tx --tls true --cafile $ORDERER_CA
# 업데이트 앵커 피어(org2)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer channel update -o localhost:7050 --ordererTLSHostnameOverride orderer.example.com -c mychannel -f ./channel-artifacts/Org2MSPanchors.tx --tls true --cafile $ORDERER_CA

      5. 체인코드 배포(mychannel에 Fabcar)

        # install dependence if not done before
pushd ../chaincode/fabcar/go
GO111MODULE=on go mod vendor
popd
# 체인코드 패키지
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer lifecycle chaincode package fabcar.tar.gz --path ../chaincode/fabcar/go/ --label fabcar_1
# org1에 배포
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer lifecycle chaincode install fabcar.tar.gz
# org2에 배포
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer lifecycle chaincode install fabcar.tar.gz
# approve
# org1
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer lifecycle chaincode approveformyorg -o localhost:7050 --ordererTLSHostnameOverride orderer.example.com --tls true --cafile $ORDERER_CA --channelID mychannel --name fabcar --version 1 --init-required --package-id fabcar_1:65710fa851d5c73690faa4709ef40b798c085e7210c46d44f8b1e2d5a062c9b0 --sequence 1
# org2
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer lifecycle chaincode approveformyorg -o localhost:7050 --ordererTLSHostnameOverride orderer.example.com --tls true --cafile $ORDERER_CA --channelID mychannel --name fabcar --version 1 --init-required --package-id fabcar_1:65710fa851d5c73690faa4709ef40b798c085e7210c46d44f8b1e2d5a062c9b0 --sequence 1
# Commit chaincode
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer lifecycle chaincode commit -o localhost:7050 --tls true --cafile $ORDERER_CA --peerAddresses localhost:7051 --tlsRootCertFiles $PEER0_ORG1_CA --peerAddresses localhost:9051 --tlsRootCertFiles $PEER0_ORG2_CA --channelID mychannel --name fabcar --version 1 --sequence 1 --init-required

      6. Fabcar Chaincode invoke and query

        # init invoke
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer chaincode invoke -o localhost:7050 --ordererTLSHostnameOverride orderer.example.com --tls true --cafile $ORDERER_CA -C mychannel -n fabcar --peerAddresses localhost:7051 --tlsRootCertFiles $PEER0_ORG1_CA --peerAddresses localhost:9051 --tlsRootCertFiles $PEER0_ORG2_CA --isInit -c '{"function":"initLedger","Args":[]}'
# query(org1)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer chaincode query -C mychannel -n fabcar -c '{"function":"queryAllCars","Args":[]}'
# query(org2)
CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer chaincode query -C mychannel -n fabcar -c '{"function":"queryAllCars","Args":[]}'

      7. bloc info 확인
        블록 정보에서 해시 값 및 height 확인

        # org1
docker exec peer0.org1.example.com peer channel getinfo -c mychannel
## 결과
2020-11-23 05:31:24.419 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
Blockchain info: {"height":7,"currentBlockHash":"H9VY/b/41Be30GLneaXcefek1Bp2CSOPxiBoxqXiRyQ=","previousBlockHash":"f7ePJEGbBrbWe31iAYW7YXIHrJLdTojpdUkNYL0heG0="}
# org2
docker exec peer0.org2.example.com peer channel getinfo -c mychannel
# 결과
2020-11-23 05:33:31.299 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
Blockchain info: {"height":7,"currentBlockHash":"H9VY/b/41Be30GLneaXcefek1Bp2CSOPxiBoxqXiRyQ=","previousBlockHash":"f7ePJEGbBrbWe31iAYW7YXIHrJLdTojpdUkNYL0heG0="}

      8. back up & restore sh 작성

      vi backup.sh

      set -ev

rm -rf backup
mkdir backup
#Copying Certificates and Configuration files
sleep 5
cp -r organizations backup # crypto-config
cp -r channel-artifacts backup #config

cd backup
mkdir peer
mkdir orderer
cd ..
#Copying Peer and orderer data
sleep 5
docker cp peer0.org1.example.com:/var/hyperledger/production/ backup/peer/
# sudo docker cp peer0.org2.example.com:/var/hyperledger/production/ backup/peer/

docker cp orderer.example.com:/var/hyperledger/production/orderer/ backup/orderer/

#All done
exit 1

      vi restore.sh

      set -ev

COMPOSE_FILE_BASE=docker/docker-compose-test-net.yaml
COMPOSE_FILE_BASE_RESTORE=docker/docker-compose-test-net-restore.yaml

#bringing network down and clearing volumes

docker-compose -f ${COMPOSE_FILE_BASE} down

docker volume prune

docker network prune

#Bringing network Up with Previous Backup
docker-compose -f ${COMPOSE_FILE_BASE_RESTORE}  up -d

#All done...
sleep 20

#querying Data

CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org1MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG1_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp CORE_PEER_ADDRESS=localhost:7051 peer chaincode query -C mychannel -n fabcar -c '{"function":"queryAllCars","Args":[]}'

CORE_PEER_TLS_ENABLED=true CORE_PEER_LOCALMSPID="Org2MSP" CORE_PEER_TLS_ROOTCERT_FILE=$PEER0_ORG2_CA CORE_PEER_MSPCONFIGPATH=${PWD}/organizations/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp CORE_PEER_ADDRESS=localhost:9051 peer chaincode query -C mychannel -n fabcar -c '{"function":"queryAllCars","Args":[]}'

exit 1

      docker-compose-test-net-restore.yaml

      # Copyright IBM Corp. All Rights Reserved.
#
# SPDX-License-Identifier: Apache-2.0
#

version: "2"

volumes:
  orderer.example.com:
  peer0.org1.example.com:
  peer0.org2.example.com:

networks:
  test:

services:
  orderer.example.com:
    container_name: orderer.example.com
    image: hyperledger/fabric-orderer:$IMAGE_TAG
    environment:
      - FABRIC_LOGGING_SPEC=INFO
      - ORDERER_GENERAL_LISTENADDRESS=0.0.0.0
      - ORDERER_GENERAL_LISTENPORT=7050
      - ORDERER_GENERAL_GENESISMETHOD=file
      - ORDERER_GENERAL_GENESISFILE=/var/hyperledger/orderer/orderer.genesis.block
      - ORDERER_GENERAL_LOCALMSPID=OrdererMSP
      - ORDERER_GENERAL_LOCALMSPDIR=/var/hyperledger/orderer/msp
      # enabled TLS
      - ORDERER_GENERAL_TLS_ENABLED=true
      - ORDERER_GENERAL_TLS_PRIVATEKEY=/var/hyperledger/orderer/tls/server.key
      - ORDERER_GENERAL_TLS_CERTIFICATE=/var/hyperledger/orderer/tls/server.crt
      - ORDERER_GENERAL_TLS_ROOTCAS=[/var/hyperledger/orderer/tls/ca.crt]
      - ORDERER_KAFKA_TOPIC_REPLICATIONFACTOR=1
      - ORDERER_KAFKA_VERBOSE=true
      - ORDERER_GENERAL_CLUSTER_CLIENTCERTIFICATE=/var/hyperledger/orderer/tls/server.crt
      - ORDERER_GENERAL_CLUSTER_CLIENTPRIVATEKEY=/var/hyperledger/orderer/tls/server.key
      - ORDERER_GENERAL_CLUSTER_ROOTCAS=[/var/hyperledger/orderer/tls/ca.crt]
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric
    command: orderer
    volumes:
      - ../backup/system-genesis-block/genesis.block:/var/hyperledger/orderer/orderer.genesis.block
      - ../backup/organizations/ordererOrganizations/example.com/orderers/orderer.example.com/msp:/var/hyperledger/orderer/msp
      - ../backup/organizations/ordererOrganizations/example.com/orderers/orderer.example.com/tls/:/var/hyperledger/orderer/tls
      - ../backup/orderer/orderer:/var/hyperledger/production/orderer
    ports:
      - 7050:7050
    networks:
      - test

  peer0.org1.example.com:
    container_name: peer0.org1.example.com
    image: hyperledger/fabric-peer:$IMAGE_TAG
    environment:
      #Generic peer variables
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      # the following setting starts chaincode containers on the same
      # bridge network as the peers
      # https://docs.docker.com/compose/networking/
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_test
      - FABRIC_LOGGING_SPEC=INFO
      #- FABRIC_LOGGING_SPEC=DEBUG
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_PROFILE_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/etc/hyperledger/fabric/tls/server.crt
      - CORE_PEER_TLS_KEY_FILE=/etc/hyperledger/fabric/tls/server.key
      - CORE_PEER_TLS_ROOTCERT_FILE=/etc/hyperledger/fabric/tls/ca.crt
      # Peer specific variabes
      - CORE_PEER_ID=peer0.org1.example.com
      - CORE_PEER_ADDRESS=peer0.org1.example.com:7051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:7051
      - CORE_PEER_CHAINCODEADDRESS=peer0.org1.example.com:7052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:7052
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer0.org1.example.com:7051
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer0.org1.example.com:7051
      - CORE_PEER_LOCALMSPID=Org1MSP
    volumes:
      - /var/run/:/host/var/run/
      - ../backup/organizations/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/msp:/etc/hyperledger/fabric/msp
      - ../backup/organizations/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls:/etc/hyperledger/fabric/tls
      - ../backup/peer/production:/var/hyperledger/production
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/peer
    command: peer node start
    ports:
      - 7051:7051
    networks:
      - test

  peer0.org2.example.com:
    container_name: peer0.org2.example.com
    image: hyperledger/fabric-peer:$IMAGE_TAG
    environment:
      #Generic peer variables
      - CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
      # the following setting starts chaincode containers on the same
      # bridge network as the peers
      # https://docs.docker.com/compose/networking/
      - CORE_VM_DOCKER_HOSTCONFIG_NETWORKMODE=${COMPOSE_PROJECT_NAME}_test
      - FABRIC_LOGGING_SPEC=INFO
      #- FABRIC_LOGGING_SPEC=DEBUG
      - CORE_PEER_TLS_ENABLED=true
      - CORE_PEER_GOSSIP_USELEADERELECTION=true
      - CORE_PEER_GOSSIP_ORGLEADER=false
      - CORE_PEER_PROFILE_ENABLED=true
      - CORE_PEER_TLS_CERT_FILE=/etc/hyperledger/fabric/tls/server.crt
      - CORE_PEER_TLS_KEY_FILE=/etc/hyperledger/fabric/tls/server.key
      - CORE_PEER_TLS_ROOTCERT_FILE=/etc/hyperledger/fabric/tls/ca.crt
      # Peer specific variabes
      - CORE_PEER_ID=peer0.org2.example.com
      - CORE_PEER_ADDRESS=peer0.org2.example.com:9051
      - CORE_PEER_LISTENADDRESS=0.0.0.0:9051
      - CORE_PEER_CHAINCODEADDRESS=peer0.org2.example.com:9052
      - CORE_PEER_CHAINCODELISTENADDRESS=0.0.0.0:9052
      - CORE_PEER_GOSSIP_EXTERNALENDPOINT=peer0.org2.example.com:9051
      - CORE_PEER_GOSSIP_BOOTSTRAP=peer0.org2.example.com:9051
      - CORE_PEER_LOCALMSPID=Org2MSP
    volumes:
      - /var/run/:/host/var/run/
      - ../organizations/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/msp:/etc/hyperledger/fabric/msp
      - ../organizations/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls:/etc/hyperledger/fabric/tls
      - peer0.org2.example.com:/var/hyperledger/production
    working_dir: /opt/gopath/src/github.com/hyperledger/fabric/peer
    command: peer node start
    ports:
      - 9051:9051
    networks:
      - test
      1. troubleshooting
      • org1에서 백업 및 복구를 진행
      • org2에서 채널 join 및 체인코드 설치 후 데이터 동기화 진행
